Ariens, Gravely Ride On Lawn Mower Side Discharge Blade 17.35 Inch For 34 Inch & 50 Inch Decks 03971900, 03746500, BLR7959


ALL BAR BLADES ARE SOLD AS SINGLES, ORDER THE QTY REQUIRED TO MAKE A SET


Replaces OEM Number Description Length Centre
Hole
Diam.
Width
03971900, 03746500 Ariens, Gravely Ride On Lawn Mower Side Discharge Blade 17.35"(440.6mm) 5/8” (15.8mm) 2 1/4" (57.2mm)

Fits: 34" (864 mm) Cut Ariens Zoom 34 (915157 models with serial # 000101 -009999, 010000 - 029999, 030000 - 034999, 035000 and onwards and 915189 with serial # 045000 and onwards), Zoom 34 Carb (915169 models with serial # 000101 - 009999, 010000 - 029999, 030000 -034999, 035000 and onwards), Zoom 34 Carb (915193 models with serial # 000101 - 044999) zero turn ride on lawnmower models.
Qty required per unit: 2 blades required for 34" cut
Fits: 50" (1270 mm) Cut Ariens Zoom 50 (915161 models with serial # 000101 - 009999, 010000 - 029999, 030000 - 034999, 035000 - 044999, 045000 and onwards) zero turn ride on lawnmower models.
Qty required per unit: 3 blades required for 50" cut
Fits: 34" (864 mm) Cut GRAVELY ZT 34 (915146 models with ser # 000101-009999, 010000 - 029999, 030000 - 034999, 035000 and onwards and 915190 models with ser # 000101 - 055999, 056000 and onwards), zero turn ride on lawnmower models.
Qty required per unit: 2 blades required for 34" cut
Fits: 50" (1270 mm) cut GRAVELY ZT 50 (915150 models with ser # 000101-009999, 010000 - 029999, 030000 - 034999, 035000 and onwards and 915180 models with ser # 035000 - 044999, 045000 and onwards), zero turn ride on lawnmower models.
Qty required per unit: 3 blades required for 50" cut



No Attachment Found
  • Availability: 0 Units in Stock
  • Availability: Leaves our warehouse within 3-6 business days
  • Product Warranty: 3 Months Warranty
  • Manufactured by: GA Spares
  • Condition: NEW
  • SKU: BLR7959
