SUPASWIFT, LONCIN ENGINE SSV550XP VERTICAL SHAFT, ENG8549

Description: SupaSwift SSV550XP, 15.5 hp, 11.5 kW, 547 cc Single Cylinder OHV Vertical Shaft
4-Stroke Petrol Engine
Editorial: The SupaSwift SSV550XP is a durable and reliable 11.5 kW single cylinder OHV
4-stroke petrol engine suitable for a variety of outdoor power equipment including
ride-on lawn mowers. With premium features such as a forged crankshaft, metal cam
shaft, cast-iron cylinder liner, OHV design and an oil filter this engine is ready
to provide many years of trouble free service.
Warranty: 3 Years domestic, 90 days commercial. For further details on our warranty terms and
conditions including all limitations and exclusions please refer to the warranty
section on our web site or contact our friendly sales team.
Features: Cast-Iron cylinder sleeve.
Forged and carefully balanced crankshaft.
Metal camshaft.
OHV design.
Oil filter.
Proven reliability.
Conforms to Euro 5 Standards.
Suitable for ride-on mowers.
Engine: SupaSwift SSV550XP.
Type: Forced air-cooled, single cylinder OHV, vertical shaft, normally aspirated 4-stroke
petrol engine.
Displacement: 547 cc.
Bore x Stroke: 90mm x 86mm.
Cylinder: Single cylinder with cast -iron cylinder sleeve.
Compression Ratio: 8.5:1.
Net Power: 15.5 hp [11.5 kW] @ 3600 rpm (Measured in accordance with SAE J1349).
Net Torque: 33 nm @ 2600 rpm. (Measured in accordance with SAE J1349).
Horsepower (@3,600 rpm): 15.5 hp (Measured in accordance with SAE J1349).
Engine (cc): 547 cc.
Crankshaft: Forged and balanced crankshaft.
Crankshaft Diameter: (inches) 1".
Crankshaft Diameter: (mm) 25.4 mm.
PTO Shaft Type: A (1" or 25.4 mm, parallel keyway).
PTO Shaft Rotation: Anti-clockwise (viewed from the PTO side).
Cooling: Forced air-cooled.
Governor: Centrifugal mass type.
Carburettor: Butterfly type.
Choke: Manual.
Starter: Electric start.
Ignition: Transistorised magneto ignition.
Charging System: 15 amp.
Spark Plug: NGK - BPR6ES.
Spark Plug Gap: 0.6 - 0.8 mm.
Valve Clearance: Inlet Valve: 0.10 - 0.15 mm. / Exhaust Valve: 0.10 - 0.15 mm.
Lubrication: Splash and pressure lubrication system.
Oil Grade: SAE 10W/30.
Oil Filter: Yes.
Oil Capacity: 1.8 litres.
Fuel: Unleaded (minimum of 90 octane).
Fuel Capacity: Please Note: This engine does not come with a fuel tank.
Fuel Filter: No.
Air Filter: Dual element paper and foam.
Exhaust/Muffler: Yes, includes muffler and guard.
Dimensions L x W x H: 470 mm x 405 mm x 400 mm.
Dry Weight: (lb) 72.75 lb.
Copyright © Roy Gripske & Sons Pty. Ltd. 2013~2025. All Rights Reserved.
All original equipment manufacturers‘ names and part numbers and photographs or drawings of their products are used
for identification purposes only, and unless otherwise expressly stated our products are not original equipment
manufacturers parts. Unless specifically stated otherwise, we do not hold ourselves out to have any connection,
association with or the sponsorship of any original equipment manufacturers and nor do we hold that any of our products
have any approval of original equipment manufacturers.
Dry Weight: (kg) 33 kg.
International Standard: Conforms to EU5.
Standard Pack Quantity: 1
