Kawasaki Vertical Engine FR691V-FS00-S - 23HP ENG8052




OEM Number Description Specifications
FR691V-FS00-S • 1" (25.4mm) x 80mm crankshaft
• Overhead valve
• 90° V-twin
• Spin-on oil fi lter
• Pressurised lubrication
• Electronic spark ignition
• Automatic compression release
• Dual element air cleaner
• Internally vented carburettor
• Rotating grass screen
• Cast-iron cylinder liners
Not compatible with greater than 10% ethanol fuell
ENGINE TYPE Forced Air Cooled 4 stroke
Vertical Shaft OHV Petrol Engine
Number of Cylinders 2
Bore x Stroke 3.1 x 3.0 in. (78 x 76mm)
Displacement 726cm (44.3 cu.in)
Compression Ratio 8.2:1
Maximum Power 23.0HP (17.2kw) / 3600 rpm
Maximum Torque 39.5 ft lbs. (53.6.0N.m) / 2200 rpm
Oil Capacity 2.2 U.S. qt. (2.1 litre) w/Filter
Dry Weight (without muffler) 89.0 lbs. (40.4 kg)





No Attachment Found
  • Availability: 0 Units in Stock
  • Availability: Special Order
  • Product Warranty: 3 Months Warranty
  • Manufactured by: Kawasaki
  • Condition: New
  • SKU: ENG8052
