Kawasaki Vertical Engine FH680V - 23HP, 500-010




OEM Number Description Specifications
FH680V • 1 1/8" (28.6mm) crankshaft
• Overhead valve
• 90° V-twin
• Spin-on oil fi lter
• Pressurised lubrication
• Electronic spark ignition
• Automatic compression release
• Dual element air cleaner
• Internally vented carburettor
• Rotating grass screen
• Cast-iron cylinder liners
Not compatible with greater than 10% ethanol fuel
ENGINE TYPE Forced Air Cooled 4 stroke
Vertical Shaft OHV Petrol Engine
Number of Cylinders 2
Bore x Stroke 2.96 x 2.99 in. (75.2 x 76mm)
Displacement 675cc (41.2 cu.in)
Compression Ratio 8.1:1
Maximum Power 23.0HP (17.2kw) / 3600 rpm
Maximum Torque 39.8 ft lbs. (54.2.0N.m) / 2400 rpm
Oil Capacity 2.0 U.S. qt. (1.9 litre) w/Filter
Dry Weight (without muffl er) 88.2 lbs. (40.0 kg)




No Attachment Found
  • Availability: 0 Units in Stock
  • Availability: NO LONGER AVAILABLE
  • Product Warranty: -
  • Manufactured by: Stens
  • Condition: NEW
  • SKU: 500-010
