HUSQVARNA STEPPED BLADE BAR ADAPTER 5-POINT STAR HOLE, BLH409

  • Availability: Leaves our warehouse within 3-6 business days
  • Product Warranty:3 Months Warranty
  • Manufactured by: GA Spares
  • Condition: NEW
  • SKU: BLH409
Ask a Question

$75.05

Add to Cart:





Replaces OEMOutdoorking Product Description ©Dimensions
N/ANon-Genuine Husqvarna Selected 36", 38", 42", 46" And 54" Cut Stepped, 5 Point Star Hole, Swing Back Blade Conversion Carrier BarCentre Hole Type: 5-Point Star



Fits  Models
Fits: 36" (915 mm) cut Husqvarna selected ride-on lawn mower models using a 5-point star centre hole blade.
Qty required per unit: 2 bars required for 36" cut
Fits: 38" (965 mm) cut Husqvarna selected ride-on lawn mower models using a 5-point star centre hole blade.
Qty required per unit: 2 bars required for 38" cut
Fits: 42" (1067 mm) cut Husqvarna selected ride-on lawn mower models using a standard blade system with a 5-point star centre hole blade.
Qty required per unit: 2 bars required for 42" cut
Fits: 42" (1067 mm) cut Husqvarna TS242 (model 96041038400, year 2015) side discharg lawn tractors as a swing back blade carrier replacement option to the Rapid Release bar blades (please read the product note below for a full list of components required).
Qty required per unit: 2 bars required for 42" cut
Fits: 46" cut Husqvarna TS246 (model 96041038500, year 2015) side discharge lawn tractors as a swing back blade carrier replacement option to the Rapid Release bar blades (please read the product note below for a full list of components required).
Qty required per unit: 2 bars required for 46" cut
Fits: 54" (1372 mm) cut Husqvarna selected ride-on lawn mower models using a 5-point star centre hole blade.
Qty required per unit: 3 bars required for 54" cut
Features: • Converts units which came standard off the production line with bar blades and allows them to be fitted with swing back blades. Please order the swing back blades separately from the options listed below.
Stepped carrier bar
Inner "D" holes: 6.181" (157 mm)
Middle "D" holes: 7.283" (185 mm)
Outer "D" holes: 9.055" (230 mm)
Note: All blade carriers are sold as singles, order the quantity required to make up a set.
Please Note: For standard 36", 38" & 42" cut Lawn Tractor models use with our BLS3653 x 2 qty blade sets and BBN3722 x 2 qty bolt sets or for a blade and bolt combo option use our BRC5543 x 2 qty.
Or
For 54" cut: Use with our BLS3653 x 3 qty blade sets and BBN3722 x 3 qty bolt sets, or for a blade and bolt combo pack option use our BRC5543 x 3 qty.
Or
For Rapid Release 42" cut models the components required to replace the Rapid Release bar blade system are -
• Use BLH409 blade carriers x 2 qty
• Use BLH7733 mounting bolt and washer x 2 qty
• Use BLS3653 blade sets x 2 qty
• Use BBN3722 bolt sets x 2 qty
• Or use our blade and bolt combo pack option BRC5543 x 2 qty
(The above components can be used as a swing back blade option to replace Husqvarna Rapid Release bar blade OEM: 580 92 11-01)
Please Note: For this application please assemble blades and bolts using the outside blade mounting holes of the blade carrier.
Please also note: to replace the rapid release bar blade system with the swing back blade and blade carrier systems above it is necessary to remove the rapid release mounting system components and return to the conventional bolt on mounting
Or
For Rapid Release 46" cut models the components required to replace the Rapid Release bar blades are -
• Use BLH409 blade carriers x 2 qty
• Use BLH7733 mounting bolt and washer x 2 qty
• Use BLS3817 blade sets x 2 qty
• Use BBN3722 bolt sets x 2 qty
• Or use our blade and bolt combo pack option BRC5544 x 2 qty
(The above components can be used as a swing back blade option to replace Husqvarna Rapid Release bar blade OEM: 581 04 39-01)
Please Note: For this application please assemble blades and bolts using the middle blade mounting holes of the blade carrier.
**Please also note: to replace the rapid release bar blade system with the swing back blade and blade carrier systems above it is necessary to remove the rapid release mounting system components and return to the conventional bolt on mounting system for the carrier bar.
